Technical Specifications

Dimensions: L·W·H

4350×1600×2050mm

Rated Passenger Capacity

11people

Maximum Speed (Loaded)

35km/h

Minimum Turning Radius

6m

Maximum Climbing Capacity (Loaded)

25%

Braking Distance

≤5m

Driving Range (Unloaded)）

≥100km

Wheelbase (mm)

2210

Minimum Ground Clearance

200mm

Front/Rear Track (mm)

1310/1350

Curb Weight

930kg

Rated Load

700kg

Electrical system

Battery

Lead acid/lithium

Charger

Waterproof On-board Intelligent Charger

Controller

Fully Intelligent Electronic Control

Motor

AC Motor

Power Control

Power transmission system

Continuously variable speed system

Steering system

Rack and pinion steering gear

Front axle and Suspension

Independent suspension

Rear axle and suspension

Integral rear axle High-strength steel leaf spring Telescopic hydraulic shock damping

Braking system

Hydraulic brakes, dual-circuit hydraulic brakes, parking brake device

wheel

Tubeless radial tire

Appearance

Paint

Automotive Metallic Paint

Frame + Body

Steel Frame +Metal Body

Doors

Metal Material

Lights and Signals

LED combined headlight, turn signal, combined taillight, brake light, electric horn

Front Windshield

Tempered Glass

Interior

Seats

High-Quality Simulated Leather Seats

Instrument

Metal Material

Switches

Start switch, light switch, forward and reverse gear switch

Steering Wheel

336CM Steering Wheel

LED High-Efficiency Strobe Warning Light
